Description
| Parameters of Product | Lowboy Trailer |
|---|---|
| Model Type | Paver Deck |
| Capacity | 55-Ton HGG |
| Rear Deck Height | 42" |
| Lower Deck Height | 18" w/ 6" GC |
| GN Length | 147" |
| Lower Deck Length | 288" |
| Rear Deck Length (PO) | 200" |
| Rear Deck Length (Design) | 194" |
| Overall Length | 629" |
| Overall Width | 102" |
| Ground Clearance | 6" |
| KingPin Style | Fixed |
| KingPin Setting | 16" |
| Swing Clearance | 102" |
| Fifth Wheel Height | 50" |
| Ride Height | 5-Position |
| Fenders | Diamond Plate Steel Fenders |
| Motor | No |
| Flip Box Set Up | No |
| Main Beam Center | 40" |
| Deck Main Beam | 12" |
| Deck Side Rail | 12" |
| Crossmembers | 8" & 4" |
| Outrigger Type | Full Height Removable - Fabricated |
| Front Ramps | Steel 18" x 31" |
| Number of Axles | 3 |
| Axle Spacings | 49" |
| Axle Track | 76.5" |
| ABS | 2S1M |
| Axle 1 | Fixed Type 30/30 Non-ABS |
| Axle 2 | Fixed Type 30/30 ABS |
| Axle 3 | Super Lift Type 30 Non-ABS |
| Axle 4 | None |
| Suspension Type | Cush Air Ride Suspension-25K |
| Dump Type | Manual |
| Ride Height Adjuster | Yes |
| Riser (Transition) Ramp | 21° Steel D-Plate w/ Grousers |
| Rear Deck Beam | 16.5" |
| Rear Well Style | Boom & Bucket Well |
| D-Ring in Tail | 2 |
| Flip Axle Set Up | Set Up for Flip 2-Pin Design (TK) |
| Rear Deck Option (Beavertail) | No |
| Wood | Apitong Open Center |
| Wheel Covers | Steel Covered D-Plate |
| Well Decking | Removable V-Style Full Length |
| Tire | 275/70R x 22.5" H |
| Rims | Piloted Outer Aluminum |
| Notes | 1) Lockable Aluminum Tool Box Base Cover with Chain Racks in Gooseneck Base 3) Cush Air Ride Adjustment 3" +/- 3" - ***NEW STYLE IN BOLSTER*** Similar to 161112 - Differences - diamond plate transition and rear deck |
