Lowboy · Drawing

01426558

GTBN553-53-24-HGG

Capacity: 55-Ton HGG
Number of Axles: 3
Lower Deck Length: 26'
Overall Length: 639"
Rear Deck Height: 42"
Lower Deck Height: 18" w/ 6" GC
KingPin Style: 2-Position Removable
Model Type: Paver Deck

Specifications 40 of 49 fields recorded

Show empty fields

Dimensions & Capacity

Model Type	Paver Deck
Capacity	55-Ton HGG
Rear Deck Height	42"
Lower Deck Height	18" w/ 6" GC
Lower Deck Length	26'
Rear Deck Length (PO)	171"
Rear Deck Length (Design)	—
Overall Length	639"
Overall Width	102"
Ground Clearance	6"

Gooseneck & King Pin

GN Length	156"
KingPin Style	2-Position Removable
KingPin Setting	16" & 24"
Swing Clearance	110" & 102"
Fifth Wheel Height	50"
Ride Height	5-Position
Well Decking	Removable D-Plate - Full Length

Frame & Deck

Main Beam Center	40"
Deck Main Beam	12" T-1 Steel
Deck Side Rail	12" T-1 Steel
Crossmembers	8" & 4"
Outrigger Type	Full Height Removable
Front Ramps	Paver Ramps 22" x 41"
Riser (Transition) Ramp	90° w/6' Air Transition Ramps
Rear Deck Beam	16.5" T-1 Steel
Rear Well Style	Boom & Bucket Well
D-Ring in Tail	2 Ea Side
Rear Deck Option (Beavertail)	—
Wood	1.75" Apitong Full Width
Wheel Covers	Steel Covered D-Plate
Rear Bolster D-Rings	—

Axles & Suspension

Number of Axles	3
Axle Spacings	54"
Axle Track	76 1/2"
ABS	2S1M
Axle 1	Fixed Type 30/30 Non-ABS
Axle 2	Fixed Type 30/30 ABS
Axle 3	Super Lift Type 30 Non-ABS
Axle 4	—
Suspension Type	Cush Air Ride Suspension - 25K
Dump Type	Manual
Ride Height Adjuster	Turn Dial
Flip Axle Set Up	—

Wheels & Electrical

Tire	275/70R x 22.5 "H"
Rims	8.25 x 22.5 Hub Piloted All Aluminum

Options & Finish

Fenders	—
Motor	—
Flip Box Set Up	—
Wide Load Sign Cutout	—

Notes

(4) Clear lights per side - Stop, Turn, Stop, Strobe
ID Bar to be replaced with 3 3/4" lights
Digital Air Weigh Scale Mounted on Rear Bumper
Last 5 ft of Rear Deck Covered in D-Plate Steel
Chain Slots down outer rails and rear deck and 4 way center mounted slots
All controls to be mounted in rear bumper. No controls mounted in bolsters
Do not install outriggers or brackets
Trailer to include chain stops on 12" centers on both sides for the first and last 8ft of deck
Trailer to include "Oversize Load" sign and brackets for rear bumper with crossbar to function as roller stop
Trailer to include Registration holder mounted to gooseneck
All lenses to be clear
Trailer to include (1) light per outrigger, and (3) additional lights per side of gooseneck
Trailer to include 4 way plug for beacon lights at rear corners of bumper
