Lowboy · Drawing

01389131

GTBN503-52-24-GG

Capacity: 50-Ton GG
Number of Axles: 3
Lower Deck Length: 24'
Overall Length: 621"
Rear Deck Height: 43"
Lower Deck Height: 22" w/ 6" GC
KingPin Style: Fixed
Model Type: Paver Deck

Specifications 40 of 49 fields recorded

Show empty fields

Dimensions & Capacity

Model Type	Paver Deck
Capacity	50-Ton GG
Rear Deck Height	43"
Lower Deck Height	22" w/ 6" GC
Lower Deck Length	24'
Rear Deck Length (PO)	189"
Rear Deck Length (Design)	—
Overall Length	621"
Overall Width	102"
Ground Clearance	6"

Gooseneck & King Pin

GN Length	144"
KingPin Style	Fixed
KingPin Setting	16"
Swing Clearance	98"
Fifth Wheel Height	50"
Ride Height	5-Position
Well Decking	Apitong

Frame & Deck

Main Beam Center	40"
Deck Main Beam	16" T-1 Steel Std.
Deck Side Rail	16" T-1 Steel
Crossmembers	10" & 4"
Outrigger Type	Removable Std.
Front Ramps	Paver Ramps Adj Width 22" x 41"
Riser (Transition) Ramp	3:1 Ration on Riser 54" Transition
Rear Deck Beam	16.5" T-1 Steel
Rear Well Style	Wood Filled Center 1/4" Raised
D-Ring in Tail	2 Ea Side
Rear Deck Option (Beavertail)	—
Wood	1.75" Apitong Full Width
Wheel Covers	Apitong Covered
Rear Bolster D-Rings	—

Axles & Suspension

Number of Axles	3
Axle Spacings	49"
Axle Track	76.5"
ABS	2S1M
Axle 1	Fixed Type 30/30 Non-ABS
Axle 2	Fixed Type 30/30 ABS
Axle 3	Super Lift Type 30 Non-ABS
Axle 4	—
Suspension Type	Cush Air Ride Suspension - 25K
Dump Type	Manual
Ride Height Adjuster	—
Flip Axle Set Up	—

Wheels & Electrical

Tire	255/70R x 22.5 "H"
Rims	8.25 x 22.5 Hub Piloted Outer Aluminum

Options & Finish

Fenders	—
Motor	13 HP Honda - Gas
Flip Box Set Up	—
Wide Load Sign Cutout	—

Notes

Add four (4) additional 3/4" round clearance lights, each side of main deck, evenly spaced
LED work lights on GN base, facing rear of trailer
All lights to be clear lenses and chrome bezels
Chain slots down each side of main deck

No drawing image on file.
