Hydraulic Tail Products
Capacity
Overall Length
Overall Width
Gooseneck Length
Swing Clearance
5th Wheel Height
Loadwell Length
Loadwell Height
Rear Deck Height
Hydraulic Tail Length
Flip Under Ramp Length
King Pin Setting
Axle Spacing
Main Beam Center
Number of Axles
Axle Track
Cross Member
Main Frame
Axle Capacity
King Pin
Tires
Rims
Brakes
ABS
Landing Gear
Rear Folding Tail
Suspension
Lights
Connectors
Hydraulics
Winch
Decking
Number of D-Rings
Finish
00620018
Parameters of Product
Hydraulic Trailer
Model Number
00620018
Capacity
50 Ton
Overall Length
600-inch
Overall Width
102-inch
Gooseneck Length
120-inch
Swing Clearance
86-inch
5th Wheel Height
48-inch
Loadwell Length
384-inch
Loadwell Height
36-inch
Rear Deck Height
37-inch
Hydraulic Tail Length
8'
Flip Under Ramp Length
King Pin Setting
16-inch
Axle Spacing
49-inch
Main Beam Center
Number of Axles
3
Axle Track
71.5-inch
Cross Member
Jr. I-beams on 12-inch Centers
Main Frame
fabricated I-Beam
Axle Capacity
25k
King Pin
2-inch heavy duty
Tires
235/70R X 17.5 H
Rims
6.75 X 17.5, 8 hole hub piloted steel disc wheels
Brakes
12 ¼ X 7 ½
ABS
2S1M
Landing Gear
2-Speed landing gear
Rear Folding Tail
12’ hydraulic tail
Suspension
Air ride suspension
Lights
LED mounted in rubber grommets
Connectors
7 way SAE connector
Hydraulics
27 HP Kohler engine, Wet-line setup for tractor
Winch
20,000# hydraulic winch
Decking
apitong flooring
Number of D-Rings
10 Each side
Finish
Sandblast & Powder Coat
Notes
