Description
| Parameters of Product | Hydraulic Trailer |
|---|---|
| Capacity | 50 Ton |
| Overall Length | 622" |
| Overall Width | 102" |
| Gooseneck Length | 108" |
| Swing Clearance | 86" |
| Fifth Wheel Height | 49" |
| Loadwell Length | 371" |
| Loadwell Height | 36" |
| Rear Deck Height | 36" |
| Hydraulic Tail Length | 8' |
| Flip Under Ramp Length | 4' |
| King Pin Setting | 16" |
| Axle Spacing | 49” |
| Main Beam Center | 35" |
| Number of Axles | 3 |
| Axle Track | 71.5" |
| Cross Member | Jr. I-beams on 12” Centers |
| Main Frame | fabricated I-Beam |
| Axle Capacity | 25k |
| King Pin | 2” heavy duty |
| Tires | 235/70R X 17.5 “H” |
| Rims | 6.75 X 17.5, 8 hole hub piloted steel disc wheels |
| Brakes | 12 ¼ X 7 ½ |
| ABS | 2S1M |
| Landing Gear | 2-Speed landing gear |
| Rear Folding Tail | 12’ hydraulic tail |
| Suspension | Air ride suspension |
| Lights | LED mounted in rubber grommets |
| Electrical Connector | 7 way SAE connector |
| Hydraulics | 27 HP Kohler engine |
| Winch | 12,000# hydraulic winch |
| Decking | apitong flooring |
| Number Of D-Rings | |
| Finish | Black |
