Description
| Parameters of Product | Single Drop Trailer |
|---|---|
| Capacity | 40 Ton |
| Overall Length | 636" |
| Overall Width | 102" |
| Gooseneck Length | 130" |
| Swing Clearance | 92" |
| 5th Wheel Height | 49" |
| Load well Length | 504" |
| Beaver Tail Length | NA |
| Cross Member | 4" Jr. I-Beams on 24” Centers |
| Main Frame | Fabricated I-Beam |
| Side Rail | 6" Structural Channel |
| Neck | Full Width(Wood Covered) |
| Number of Axle | 2 ea |
| Axle Capacity | 25K |
| King Pin | 2" Heavy Duty |
| Tires | 255/70R X 22.5 “H” |
| Rims | |
| Brakes | 16 ½” X 7 Full Air Brakes |
| ABS | 2S1M |
| Landing Gear | 2-Speed Landing Gear-5 hole |
| Suspension | Spring Ride Suspension |
| Lighting | Lighting LED in Rubber Grommet |
| Connector | 7 Way SAE Connector |
| Decking | Apitong Flooring |
| Sandblasted | White Primed and Powder Coated Gray |
| Warranty | 1 Year |
