Description
| Parameters of Product | Lowboy Trailer |
|---|---|
| Model Type | Paver Deck |
| Capacity | |
| Rear Deck Height | 42" |
| Lower Deck Height | 24" |
| GN Length | 143" |
| Lower Deck Length | 264" |
| Rear Deck Length (PO) | 173" |
| Rear Deck Length (Design) | 174" |
| Overall Length | 581" |
| Overall Width | 102" |
| Ground Clearance | 8" |
| KingPin Style | Fixed |
| KingPin Setting | 16" |
| Swing Clearance | 98" |
| Fifth Wheel Height | 50" |
| Ride Height | 5-Position |
| Fenders | No |
| Motor | No |
| Flip Box Set Up | No |
| Main Beam Center | 40" |
| Deck Main Beam | 16" |
| Deck Side Rail | 16" |
| Crossmembers | 10" & 4" |
| Outrigger Type | Removable Standard |
| Front Ramps | Wood Filled 18" x 31" |
| Number of Axles | 3 |
| Axle Spacings | 54" |
| Axle Track | 76.5" |
| ABS | 4S2M |
| Axle 1 | Fixed Type 30/30 ABS |
| Axle 2 | Fixed Type 30/30 ABS |
| Axle 3 | Super Lift Type 30 Non-ABS |
| Axle 4 | None |
| Suspension Type | |
| Dump Type | Auto |
| Ride Height Adjuster | Yes |
| Riser (Transition) Ramp | 35° Rear Bridge Ramp |
| Rear Deck Beam | 16.5" |
| Rear Well Style | Boom & Bucket Well |
| D-Ring in Tail | 2 |
| Flip Axle Set Up | Set up for 3+1 Powered Single Axle Stinger |
| Rear Deck Option (Beavertail) | No |
| Wood | Oak Open Center |
| Wheel Covers | Steel Covered D-Plate |
| Well Decking | Removable V-Style Full Length |
| Tire | 255/70R x 22.5" H |
| Rims | Piloted Steel |
| Notes | 1) Lockable toolbox in gooseneck base 2) Liquid filled gauge located on drivers side bolster 3) Front ramps are wood filled 18" x 31" wood covered with handle and means of securing when not in use 4) Tail section to have 1/4" diamond plate of the axles with grouser bars on riser. Boom well in center with removable cover for servicing axle components and allow easy flow of winch cable 5) Mile marker 12K winch to be mounted in boomwell/center of rear deck before the rear x-member. Power to be suppled by the truck hydraulic per jumper lines with controls/quick connections on drivers side rear bolster 6) D - Rings; 6" opening, 10 on each side of main deck, 2 on the rear of the neck, 1 at the front inside of neck, 1 each side of Bolster on the tail, 2 on rear bumper 7) No logo, BLACK mudflaps 8) Quick connections - Parker #H4-62 1/2" coupler for trailer supply, H4-63 1/2 Coupler for trailer return 9) One set of outrigger boards to be supplied with trailer, stored loose in center 10) DOT inspection sticker affixed to trailer 11) Tapered front beams to lessen the load angle ***(SAME AS 160935)*** |
