Description
| Parameters of Product | Lowboy Trailer |
|---|---|
| Model Type | Paver Deck |
| Capacity | 50-Ton GG |
| Rear Deck Height | 42" |
| Lower Deck Height | 24" |
| GN Length | 131" |
| Lower Deck Length | 312" |
| Rear Deck Length (PO) | 166" |
| Rear Deck Length (Design) | Redesign |
| Overall Length | 610" |
| Overall Width | 102" |
| Ground Clearance | 8" |
| KingPin Style | Fixed |
| KingPin Setting | 16" |
| Swing Clearance | 86" |
| Fifth Wheel Height | 50" |
| Ride Height | 5-Position |
| Fenders | No |
| Motor | No |
| Flip Box Set Up | No |
| Main Beam Center | 40" |
| Deck Main Beam | 16" |
| Deck Side Rail | 16" |
| Crossmembers | 10" & 4" |
| Outrigger Type | Removable Standard |
| Front Ramps | Wood Filled 22" x 41" |
| Number of Axles | 3 |
| Axle Spacings | 49" |
| Axle Track | 76.5" |
| ABS | 4S2M |
| Axle 1 | Fixed Type 30/30 ABS |
| Axle 2 | Fixed Type 30/30 ABS |
| Axle 3 | Super Lift Type 30 Non-ABS |
| Axle 4 | None |
| Suspension Type | Cush Air Ride Suspension-25K |
| Dump Type | Auto |
| Ride Height Adjuster | Yes |
| Riser (Transition) Ramp | 35° Rear Bridge Ramp |
| Rear Deck Beam | 16.5" |
| Rear Well Style | Level Flush Across Rear Deck |
| D-Ring in Tail | |
| Flip Axle Set Up | No |
| Rear Deck Option (Beavertail) | No |
| Wood | Oak Full Width |
| Wheel Covers | Steel Covered D-Plate |
| Well Decking | Steel Covered |
| Tire | 255/70R x 22.5" H |
| Rims | Piloted Steel |
| Notes | The front cross members shall be fitted with two (2) hydraulic connectors, 3/4" Aeroquip series 5101-12 B -Extra set of (male & female) hydraulic connectors to be installed on the truck wet lines at time of delivery -Center boards removable for outriggers with spring hold downs -weight 23,000 lbs +/- 3% -flooring secured with carriage bolts and clips -full width boom well cover plates, including transition -King pin to C/L of axle #2 and #3 shall be 43' 11" to 2nd axle and 48' to 3rd axle -19 "D" Rings shall be positioned as follows: (1) on each side of gooseneck, (1) at the front, (6) evenly spaced down each side of the main deck, and (2) on each side of bridge at bolsters behind axle one and axle two. -GOODYEAR G114 Tires -Non-lettered/no logo mudflaps |
