Lowboy · Drawing

01437418

GTBN503-53-26-GG

Capacity: 50-Ton GG
Number of Axles: 3
Lower Deck Length: 26'
Overall Length: 631"
Rear Deck Height: 42"
Lower Deck Height: 22"
KingPin Style: Fixed
Model Type: Full Deck

Specifications 39 of 49 fields recorded

Show empty fields

Dimensions & Capacity

Model Type	Full Deck
Capacity	50-Ton GG
Rear Deck Height	42"
Lower Deck Height	22"
Lower Deck Length	26'
Rear Deck Length (PO)	172"
Rear Deck Length (Design)	—
Overall Length	631"
Overall Width	102"
Ground Clearance	6"

Gooseneck & King Pin

GN Length	147"
KingPin Style	Fixed
KingPin Setting	16"
Swing Clearance	102"
Fifth Wheel Height	50"
Ride Height	5-Position
Well Decking	Removable V-Style - Full Length

Frame & Deck

Main Beam Center	40"
Deck Main Beam	16" T-1 Steel Std.
Deck Side Rail	16" T-1 Steel
Crossmembers	10" & 4" on 12" Centers
Outrigger Type	Removable Std.
Front Ramps	Paver Ramps 22" x 41"
Riser (Transition) Ramp	90° w/6' Air Transition Ramps
Rear Deck Beam	16.5" T-1 Steel
Rear Well Style	Boom & Bucket Well
D-Ring in Tail	2 Ea Side
Rear Deck Option (Beavertail)	—
Wood	1.75" Apitong - Open Center
Wheel Covers	Steel Covered D-Plate
Rear Bolster D-Rings	—

Axles & Suspension

Number of Axles	3
Axle Spacings	54"
Axle Track	76 1/2"
ABS	4S2M
Axle 1	Fixed Type 30/30 ABS
Axle 2	Fixed Type 30/30 ABS
Axle 3	Super Lift Type 30 Non-ABS
Axle 4	—
Suspension Type	Cush Air Ride Suspension - 25K
Dump Type	Auto
Ride Height Adjuster	—
Flip Axle Set Up	—

Wheels & Electrical

Tire	255/70R x 22.5 "H"
Rims	8.25 x 22.5 Hub Piloted Steel

Options & Finish

Fenders	—
Motor	—
Flip Box Set Up	—
Wide Load Sign Cutout	—

Notes

Rear deck to have grouser bars on 8" centers
Include "Oversize" Load Sign and brackets
Amber Strobes to be mounted in far outside corners
Expanded metal in 1st bay with lockable lid & 2nd bay open storage behind GN
Additional Holes to be added to coverplate for draining stored items
Trailer to include 1 air brake connector kit with bright colored, coiled air lines
Trailer to include 7-wire, ATA approved receptacle for trailer light jumper cable
Trailer to include removable center ramp, wood filled
Hub-odometer to be mounted on first axle on street side
Air Line connectors to be Wabco 9522010180/90
Trailer to include Meritor Tire Inflation System on All Axles

No drawing image on file.
