00600293

Parameters of Product

Flatbed Trailer

Model Number

GTFF402-48

Model Type

Regular

Capacity

40 Ton

Overall Length

576-inch

Overall Height w/Front Header

Overall Width

102-inch

5th Wheel Height

48-inch

Rear Deck Height

54-inch

Front Deck Height

59-inch

King Pin Setting

30-inch

Swing Clearance

104-inch

Axle Spacing

49-inch

No. of Axles

Main Beam Center

44-inch

Axle Track

Cross Members

4-inch Jr. I-Beams on 12-inch Centers

Main Frame

Fabricated I-Beam

Side Rails

6-inch Structural Channel

Rear Cross Member

Stake Pockets

YES

Axles

25000 lbs

King Pin 5th Wheel

2-inch Heavy Duty

Tires

11R X 22.5 H

Wheels

Brakes

ABS

2S1M

Landing Gear

17-inch Travel, 2-Speed Landing Gear

Suspension

Tandem Spring Ride

Lighting

Lighting LED in Rubber Grommet

Connector

7 way SAE connector

Tie Downs

Winches and Webbings

YES

Container Locks

Front Header

Decking

Apitong Flooring

Finish

Sandblast & Powder Coat (BLACK)
